VX 9000 Controller

Extreme Networks

VX 9000 Controller

SKU: N/A
Pre Order

Request a Quote

Looking for the right solution for your business? Share your requirements with us and our team will prepare a customised quotation tailored to your needs.

Provide as much detail as possible—such as project scope, site location, and timeline—so we can better understand your requirements the most suitable solution. We’ll review your request and get back to you shortly.
What's In the Box
Features

VX 9000 Controller – High Capacity Virtualized software-based WLAN controller.
Comprehensive Cloud-Ready Wireless Services and a Single Point of Control for Any Size Enterprise that required on-premises controller.

Support up to 40,000 Access Point that’s best fit to Small, Medium to Large Enterprise and Service Provider Managed Wi-Fi by Flexible Hardware Server Specification sizing.

Comprehensive Integrated Network Security Services
Wired/wireless firewall, a built-in Wireless Intrusion Protection System (WIPS), an integrated IPSec VPN gateway, AAA radius Server, and secure guest access with a captive web portal, MAC-based authentication, 802.11w to secure management frames, NAC support, anomaly analysis, and advanced security services, such as role-based firewall

Plug-and-Play
Fast and easy zero-touch installation plus rule-based access point and NX-7500/NX-5500 adoption from all locations automates equipment discovery and deployment

Simplified License Management for Large Distributed Enterprises

  • Distribute and use licenses based on actual load per site/location — no need to provision each location individually
  • Eliminates the need to provision devices in both local offices and the NOC with access point licenses
  • Support Hardware Redundancy with High Availability.

Default appliance licenses manage 64 APs and options with add on licenses pack of :

  • AP License incremental of 16
  • AP License incremental of 64
  • AP License incremental of 256
  • AP License incremental of 512
  • AP License incremental of 1024
Specifications

System Capacity & Scalability

  • Controller Type: Virtualized software-based WLAN controller (requires on-premises or cloud hosting)
  • Maximum Access Point Capacity: Up to 40,000 APs per controller instance
  • Target Environments: Small, Medium, and Large Enterprises; Service Provider Managed Wi-Fi

Supported Platforms & Deployment

  • Deployment Models: Private Cloud, Public Cloud, or Network Operations Center (NOC)
  • Supported Hypervisors & Cloud Platforms: VMware ESXi, Citrix Xen, Microsoft Hyper-V, and Amazon EC2 Cloud
  • Installation Method: Zero-touch plug-and-play with rule-based device adoption (supports APs, NX-7500, and NX-5500)

Networking & Security Services

  • Firewall: Integrated wired and wireless role-based firewall
  • Intrusion Prevention: Built-in Wireless Intrusion Protection System (WIPS) and anomaly analysis
  • Authentication & Access: AAA RADIUS Server, MAC-based authentication, NAC support, and captive web portal for secure guest access
  • VPN & Encryption: Integrated IPSec VPN gateway
  • Frame Protection: 802.11w support to secure management frames

High Availability & Licensing

  • Redundancy: Full support for hardware redundancy and High Availability (HA) configurations
  • Base License: Includes management for 64 Access Points out-of-the-box
  • License Allocation: Dynamic, load-based distribution across remote sites and local offices without manual provisioning
  • Available AP Expansion Licenses: Available in increments of 16, 64, 256, 512, and 1,024 APs
Documentations

Datasheet

Image Disclaimer:

Product images are for illustrative purposes only. Actual product colors, textures, sizes, and details may vary due to lighting, screen settings, or production changes. Please refer to the product description for accurate specifications.
